Description
The Quantum Edge 3 is the culmination of 8 years of product improvement and innovation. Upgraded SRS (Smooth Ride Suspension) provides a smooth, comfortable ride and advanced stability. Optional iLevel is available at 7km/h with up to 12” of power adjustable seat height. Standard features include LED fender lights, a USB charger, and drive wheel colour accents. The Edge 3 accepts a complete range of seating and electronics options and is available in a total of 14 colour options, including seven brand-new, bold colours.
Features:
- SRS (Smooth Ride Suspension)
- Front and rear LED fender lights
- USB charger
- Drive wheel
- Colour accents.
- Optional iLevel is available at 4.5 mph with up to 12″ of power-adjustable seat height.
Specifications:
| Drive wheels | Standard: 35.6cm (14″) solid Optional: 35.6cm (14″) pneumatic |
| Castors | Front: 15.2cm (6″) solid Rear: 15.2cm (6″) solid |
| Maximum speed | Up to 9.6km/h Up to 7.24km/h with iLevel activated |
| Ground clearance | 6.9cm (battery tray) |
| Turning radius (without front riggings) | 52.1cm |
| Overall length (without front riggings) | 82cm (32.23”) |
| Base width | 62.2cm (24.4”) |
| Seat width | Static seat: 10″ – 22” (25.4cm – 55.9cm) Power tilt and tilt/lift: 12″-22″ (30.5cm – 55.9cm) |
| Seat depth | Static seat: 10″ – 22” (25.4cm – 55.9cm) Power tilt and tilt/lift: 12″-22″ (30.5cm – 55.9cm) |
| Seat to floor height | Static seat: 16.5″ – 18.5” (41.9cm – 47cm) Power tilt: 17.5″ – 19.5” (44.5cm – 49.5cm) Lift and tilt: 17.5″ – 19.5” (44.5cm – 49.5cm) |
| Manual recline | Yes |
| Battery size | NF-22 (2) |
| Battery weight | 17.24kg each |
| Available electronics | 120A Q-Logic 3 EX |
| Battery charger | 8A Off-board |
| Motor packages | Two-pole, mid-wheel drive |
| Weight capacity | 136kg |
| Base weight (without seating system) | 63kg |
